Specifications

• Height: 1.25 in
• Length: 3 in
• Weight: 0.2287 lbs
• Width: 1 in

Dimensions

• Height BX (IN): 2
• Max Insulation OD (IN): 1.372
• Weight BX (LB): 2.434
• Width BX (IN): 6.1875

Additional Technical Specifications

• Conductor Type: Stranded

Additional Class Attributes

• Barrel Marking: Hard
• Flared End: No
• Mounting Method: Bolted
• Number of Mounting Holes: 2
• Sight Window: No
• Slotted: No

Material and Finish

• Conductor Material: Aluminum, Copper
• Connector Finish: Tin
• Material: Aluminum

Bolt and Screw Sizes

• Mounting Bolt/Stud Size: 1/2 to 5/8

Environment and Temperature

• Temperature Rating: 90°C

Color

• Color: Silver

Conductor Ranges

• Conductor Range AL Stranded (Primary, run, main, line): 750 kcmil - 1/0 Str
• Conductor Range CU Stranded (Primary, run, main, line): 750 kcmil - 1/0 Str

Voltage

• Voltage Rating: 35 kV

Testing Standards

• Prop65 Compliance: This product is in compliance with Prop65. It is not known to contain any chemicals associated with this regulation
• ROHS Indicator: IND
• UL Control Number: 453G
• UL / CULUS Specification: UL 486A/B Listed
• UL File Number: E6207

General

• Bag Quantity: 1
• Carton Quantity Description: STD PACK QTY 10
• Direct Burial: No
• Dual Rated: Yes
• NEMA Code: 0-000-1
• UPC Code: 78366901019
