Specifications

• Height: 0.847 in | 21.5138 mm
• Length: 1.34 in | 34.036 mm
• Weight: 0.021 lbs
• Width: 0.625 in | 15.875 mm

Additional Technical Specifications

• Conductor Type: Stranded

Dimensions

• Dimension G (IN): 0.31
• Dimension G (mm): 7.874
• Drive Type Main: Slotted
• Height (mm): 21.5138
• Length (mm): 34.036
• Mounting Hole Diameter (IN): 0.297
• Mounting Hole Diameter (mm): 7.5438
• Tang Length (IN): 0.82
• Tang Length (mm): 20.828
• Tang Thickness (IN): 0.156
• Tang Thickness (mm): 3.9624
• Tang Width (IN): 0.625
• Tang Width (mm): 15.875
• Width (mm): 15.875

Material and Finish

• Conductor Material: Copper, Aluminum
• Connector Finish: Tin
• Material: Aluminum
• Wire Binding Hardware Finish: Tin
• Wire Binding Hardware Material: Aluminum

Bolt and Screw Sizes

• Mounting Bolt/Stud Size: 1/4
• Number of Wire Binding Screws per Port: 1
• Wire Binding Screw Size: 7/16
• Wire Binding Torque: 10 - 14 AWG = 35, 2/0 - 3 AWG = 50, 8 AWG = 40, 4 - 6 AWG = 45

Additional Class Attributes

• Anti-Turn Key: Yes
• Connection: Mechanical
• Contains DE-OX®: No
• Mounting Hole Type: Thru
• Number of Conductors: 1
• Number of Mounting Holes: 1
• Number of Poles: 1
• Number of Ports / Wireways: 1

Environment and Temperature

• Temperature Rating: 90°C

Conductor Ranges

• Conductor Range AL Stranded (Primary, run, main, line): 2/0 Str - 6 Str
• Conductor Range CU Stranded (Primary, run, main, line): 2/0 Str - 6 Str

Color

• Color: Silver

Voltage

• Voltage Rating: 35 kV

Testing Standards

• CSA File Number: LR-29601
• CSA Standard: C22.2 No. 65-03
• Prop65 Compliance: This product is in compliance with Prop65. It is not known to contain any chemicals associated with this regulation
• UL Control Number: 453G
• UL / CULUS Specification: UL 486A/B Listed
• UL File Number: E6207

General

• Bag Quantity: 1
• Carton Quantity Description: STD PACK QTY 15
• Direct Burial: No
• Dual Rated: Yes
• NEMA Code: S-588-3
• UPC Code: 78366999214
