Specifications

• Country of Origin: United States
• Color Code - Side A: Pink
• Color Code - Side B: Red
• Conductor - ACSR Str Size A: 4/0 (6/1) Penquin AWG
• Conductor - ACSR Str Size B: 2 (6/1) Sparrow AWG;2 (7/1) Sparate AWG
• Conductor - ACSR Str Size B Range: 2 (6/1) Sparrow AWG-2 (7/1) Sparate AWG
• Conductor - AL Str Size A: 4/0 AWG
• Conductor - AL Str Size B: 1 AWG, 2 AWG
• Conductor - AL Str Size B Range: 1 AWG-2 AWG
• Conductor - Copper Str Size A: 4 AWG
• Conductor - Copper Str Size B: 1 AWG, 2 AWG
• Conductor - Copper Str Size B Range: 1 AWG-2 AWG
• Dimension - L Length Overall mm: 102 mm
• Dimension - Length Overall inch: 4 in
• Dimension - Outside Diameter inch: .3125 in
• Plated: N
• Plating Type: Unplated
• Prefilled Oxide Inhibitor: Y
• Product Type: Compression
• Standards - RoHS Compliance Status: CM
• Trade Name: LINKIT™
• Type: Service Entrance, Uninsulated
• Certification Agency: Proposition 65
• Class Code: B30
• Freight Class Code: 16027000
• Harmonization Code: 8535908020
• Image Actual Or Representative: A
• Lead Time: 12 wk
• Sub Class Code: B30B3UF
• Die Index: 249;K-840
• UL Listed: No
• Material: Aluminum
• Base Unit of Measure: EA
• BOX SIZE: 5.125x7.373x6.438 (in)
• Carton - Gross Weight per Pack: 4.250 lb.
• Carton - Number of Sub Packs: 25
• Carton - Pack Description: Carton
• Carton - SCC-14 Next Lower Level Sub Pack: 00781810146002
• Carton - Total Units: 25
• Case - SCC-14 Next Lower Level Sub Pack: 30781810146003
• Package - GTIN - Package: 30781810146003
• Package - Total Units: 25 EA
• Package Quantity: 25 EA
• Package Weight: 0.000 lb.
• Pallet - GTIN - Package: 70781810146001
• Pallet Height: 46.750 in
• Pallet Length: 48.000 in
• Pallet Weight: 1303.000 lb.
• Pallet Width: 40.000 in
• Standard Package Quantity: 25

Certifications

• CSA Approved: No
• cULus: No
• ETL: No
• UL Recognized: No
