Features

• Neoprene Bushing Compressed by Cable Collar Prevents Entrance of Water
• Bushing is Highly Resistant to Hydrocarbon Deterioration and is Self-Extinguishing
• Contacts Exert Constant Pressure Along Entire Contact Surface and Provide Electrical Continuity
• Insulating Blocks Provide Greatest Di-Electric and Mechanical Strength and Lowest Arc Tracking
• Designed to Supply Power to Portable or Fixed  Electrical  Equipment Such as Motor Generator Units, Welders, Pumps, Compressors, Cellular Relay Stations, SCR/VFD Houses and Similar Equipment
• Ideal for Use in "Ship-To-Shore" and Backup/Temporary Power Applications
• Rough Usage Construction

Additional Information

• Wire Size 250 MCM to 1/0 AWG
• Wire Recess Diameter 0.687 Inch
• Insulating Block Material Natural Glass Filled Polyester
• Spring Material Brass with Beryllium Copper
• Enclosure Rating NEMA 3/4/4X
• Ambient Temperature Rating -13 to 104 Deg F
• Applicable Standard NEC/CEC

Specifications

• Type: Reverse Service
• Constructional Feature: Weatherproof
• Voltage Rating: 600 Volt AC 50/400 Hertz 3-Phase, 250 Volt DC
• Current Rating: 200 Amp
• Number of Poles: 4
• Number of Wires: 4
• Grounding Style: 1, Shell
• Door Type: Spring
• Material: Epoxy Powder Coated Copper-Free Aluminum
• Approval: UL 1682/1686/50E, CSA C22.2
