Description
Features
Additional Information
- RoHS/REACH Compliant
- Number of Conductor 1
- Jacket Thickness 7 Mil
- Insulation Thickness 50 Mil
- Applicable Standard NEMA WC70/ICEA S-95-658, Federal Specification A-A-59544, NFPA 70
Specifications
- Type: THHN
- Voltage Rating: 600 Volt
- Current Rating: 110 Amp (60 Deg C), 130 Amp (75 Deg C), 145 Amp (90 Deg C)
- Conductor Material: Copper
- Conductor Size: 1 AWG
- Stranding: 19-Strands
- Jacket Material: Nylon
- Insulation Material: PVC
- Insulation Color: Black
- Outer Diameter: 435 Mil
- Length: 500 Foot
- Temperature Rating: 90 Deg C (Dry)
- Weight: 299 Pound per 1000 Foot
- Package Type: Reel
- Approval: UL 83/758/1063/1581, UL (Canada and US), CSA C22.2
Downloads
Specification/TechnicalMore Information
Manufacturer Catalog Number
THHN-1-BLK-19STR-CU-500R WIRE
Weight
0.3167
Length
500
Color
Black
Conductor Material
Copper
Conductor Size
1
Current
110 amperes
Strands
Stranded
Voltage
600 volts
Wire Color
Black
