Specifications

• Fixture Type: Wall Pack
• Finish: Bronze
• Wattage: 80
• Lumen Output: 9600L-10000L
• CCT (Kelvin): 3000K/4000K/5000K
• Temperature: Warm to Cool White
• IP Rating: IP65
• Indoor or Outdoor Fixture: Outdoor
• Technology: LED
• Color Temperature: Warm to Cool White
• CRI: 80
• Voltage: 120V-277V
• Beam Angle: 90x100
• Rated Hours: 50000
• Operating Temperature: -40C (-40F) to a maximum of +40C (+104F)
• Dimmable: Yes - Dimmable
• Lens Material: Impact Resistant PC
• Surge Protection: Built-in surge protection - 4KV
• Weight (lb.): 5.73
• Material: Die-Cast Aluminum

Dimensions

• Height (in.): 5.10
• Width (in.): 12.61
• Extension (in.): 6.86

Compliance

• Safety Listing: cULus
• Location Rating: Wet
• Energy Star: No
• DLC Approved: Yes
• DLC ID: PLN9FQOJ5TZA
• California Prop 65: Lead
• RoHS Compliant: Yes
• FCC Compliant: Yes

Additional Information

• Warranty: 5 Year Limited - Fixtures
