Features

• Cast Aluminum Housing with Internal Heatsink
• Bronze Polyester Powder Coat Paint Finish
• Shatter-Resistant Borosilicate Lens
• Five NPT 1/2 Inch Threaded Hubs for Additional Mounting or Control Options
• 0 to 10V Driver Standard for Dimming and Building Control
• RoHS Compliant

Additional Information

• Intensity 16945 Lumen
• Power Factor 0.9
• Input Current Rating 1.11 Amp at 120 Volt, 0.48 Amp at 277 Volt
• Temperature Rating -22 to 112 Deg F (Ambient)
• Color Temperature 5000 Kelvin
• Efficacy 144 Lumen per Watt
• Energy Saving Replacement 400W HID
• Color Rendering Index 80
• Rated Life 50000 Hour
• Enclosure Type IP65
• Surge Protection 6 Kilovolt
• Drive Type 0 to 10 Volt Dimmable
• Total Harmonic Distortion Less than 20 Percent
• Application Wet Location

Specifications

• Type: Semi-Cutoff, Traditional, Outdoor
• Lamp Type: LED
• Lamp Wattage: 120 Watt
• Lamp/Ballast Voltage: 120 to 277 Volt AC, 60 Hertz
• Lamp Included: Yes
• Refractor/Lens Type: Borosilicate Glass
• Housing Material: Die-Cast Aluminum
• Finish: Bronze Polyester Powder Coated
• Size: 14.7 Inch Length x 9.5 Inch Width x 7.7 Inch Height
• Approval: ETL (Canada and US), DLC (Standard)
