Features

• Leviton produces lamp holders for virtually every light source equipped with incandescent, fluorescent, or LED lamps. Lamp-holders include incandescent medium base, and specialty sizes & fluorescent lamp holders, in addition to a large line of porcelain lamp holders including pulse-rated mogul-base products, and an extensive selection of devices for high-intensity lamps.

Specifications

• Country of Origin: Please Contact Customer Service
• RoHS Compliant: True

Electrical Specifications

• Availability: Distribution
• Circuit: Single Circuit
• Construction: One-Piece
• Fits Outlet Box Size: 3-1/4 or 4 Inch
• Lamp Socket Base: Medium
• Max. Lamp Wattage: 660W
• Mounting Type: Twist-Lock
• Operator Type: Pull Chain
• Sequence: ON-OFF
• Standards and Certifications: UL/CSA
• Termination: 2 Terminal Screws w/Captive Clamps
• Voltage: 250 VAC
• Warranty: 1-Year Limited
• Wiring Access: Top Wired

Material Specifications

• Availability: Distribution
• Body Material: White Urea
• Circuit: Single Circuit
• Color: White
• Fits Outlet Box Size: 3-1/4 or 4 Inch
• Lamp Socket Base: Medium
• Mounting Type: Twist-Lock
• Operator Type: Pull Chain
• Sequence: ON-OFF
• Shell Material: Aluminum
• Socket Shell Material: Aluminum
• Termination: 2 Terminal Screws w/Captive Clamps

Mechanical Specifications

• Availability: Distribution
• Body Material: White Urea
• Circuit: Single Circuit
• Color: White
• Construction: One-Piece
• Fits Outlet Box Size: 3-1/4 or 4 Inch
• Lamp Socket Base: Medium
• Mounting Type: Twist-Lock
• Operator Type: Pull Chain
• Socket Shell Material: Aluminum
• Termination: 2 Terminal Screws w/Captive Clamps
• Torque Range: 14 – 18 in.-lbs

Standards and Certifications

• CSA Certified: File LR-1863
• UL Listed: File E3810

Product Features

• Lamp Base: Medium
• Lampholder Type: Outlet Box Mount
• Light Type: Incandescent

Downloads

Instruction Sheet
