Features

• Four breaker spaces
• 3-SPST mechanism (P1353ME) controls single- and two-speed filter pumps, cleaner/booster pumps and pool/spa landscape lighting
• Load center dead front has two knockouts for switches or GFCIs
• P1353ME and MultiWave® controllers sold separately
• Wiring devices may be installed in these load centers with the use of Standoffs, sold separately
• Also compatible with T100 Series

Prop 65

• Please see the Warning @ www.P65Warnings.ca.gov - DEHP

Specifications

• Country of Origin: Canada
• Product Height: 16.875 in; 428.6 mm
• Product Depth: 4.75 in; 120.7 mm
• Warranty Period: 1-Year limited
• Color: Beige
• Applications: Distribution/Control Panel; Motor Control; Pump Control
• Input Voltage Ranges: 120/240 VAC, 50/60 Hz
• Number Of Breaker Knockouts: 4
• Number Of Circuits: 3
• Enclosure Type: 3R Beige metal
• Switch Type: 3-SPST
• Load Center Ratings: 60 A, 120 VAC; 60 A, 240 VAC; 60 A, 208 VAC, Single Phase
• PDF Standards And Certifications: cCSAus
• Material: Metal

Certifications

• CSA Certification: cCSAus

Load Ratings

• Tungsten Load Ratings: 5 A, 120 VAC, 50 Hz; 5 A, 240 VAC, 50 Hz; 5 A, 120 VAC, 60 Hz; 5 A, 240 VAC, 60 Hz
• Tungsten Load Ratings Ranges: 5 A, 120/240 VAC, 50/60 Hz
• Resistive Load Ratings: 17 A, 120 VAC, 50 Hz; 17 A, 240 VAC, 50 Hz; 17 A, 120 VAC, 60 Hz; 17 A, 240 VAC, 60 Hz
• Resistive Load Ratings Ranges: 17 A, 120/240 VAC, 50/60 Hz
• Motor Load Ratings Ranges: 80 LRA @ 120/240 VAC, 50/60 Hz; 17 FLA @ 120/240 VAC, 50/60 Hz

Knockout

• Knockout Dimensions Bottom: (1) 1 1/8" diameter hole, (6) 1/2" - 3/4", (3) 3/4" - 1"
• Knockout Dimensions Back: (1) 3/4" - 1"
• Knockout Dimensions Left: (2) 1/2" - 3/4"
• Knockout Dimensions Right: (1) 1 3/4" x 2 3/4"
• Number Of Receptacle Switch Knockouts: 2
