Specifications

• Brand Name: Milbank
• Type: Ringless Meter Socket
• Application: Meter Socket
• Standard: UL Listed;Type 3R
• Voltage Rating: 600 Volts Alternating Current
• Amperage Rating: 200 Continuous Ampere
• Phase: 1 Phase
• Frequency Rating: 60 Hertz
• Size: 4.5L x 13W x15.25H
• Number of Main Breakers: 0
• Main Breaker Size: No Main Breaker
• Cable Entry: Underground with Side Wireway
• Terminal: Lay in
• Insulation: Glass Polyester
• Mounting: Surface Mount
• Material: G90 Galvanized Steel with Powder Coat Finish
• Number of Jaws: 4 Terminal
• Bypass Provision: Horn Bypass
• Number of Meter Positions: 1 Position
• Equipment Ground: Triplex Ground
• Hub/Closing Plate: Plain Top
• Line Side Wire Range: 6 AWG - 350 kcmil
• Load Side Wire Range: 6 AWG - 350 kcmil
• Barrel Lock Provision: 7/8 Inch Knockout and Angle Bracket For Barrel Lock Provision
• Number of Receptacles: 0
• Height: 15.25 IN
• Length: 4.5 IN
• Width: 13 IN
• UNSPSC Number: 39121102
• Product Family Code: 4T20
• Product Family Disclaimer: Please consult serving utility for their requirements prior to ordering or installing, as specifications and approvals vary by utility and may require local electrical inspector approval. All installations must be installed by a licensed electrician and must comply with all national and local codes, laws and regulations. Milbank reserves the right to make changes in specifications and features shown without notice or obligation.
