Features

• Drawn steel construction with nonmetallic sheathed cable (NMSC)
• 4 in. x 1-1/2 in. deep
• Includes plaster ears for "cut-in" or "old work" applications
• Supplied with three 1/2 in. knockouts
• Combination Phillips/slotted screw heads
• 15.5 cu. in. capacity

Specifications

• Country of Origin: China
• Actual Depth: 2 in
• Buy American Compliant: Contact Manufacturer
• Dimensions: 2 in x 4.75 in x 3.64 in
• Width: 4.750 in
• Each - Width: 4.750 in
• Height: 3.64 in
• Product Type: Steel Boxes and Covers
• Color: Gray
• Cubic Capacity: 15.5 cu.in
• Depth: 1.5 in
• Knockouts: 1/2 in
• Length: 2 in
• Size: 2 in x 4.75 in x 3.64 in
• Standard: UL Listed
• Type: Box
• Bracket Type: No Bracket
• Weight: 0.594 lb.
• ARRA Compliant: Contact Manufacturer
• Class Code: D01
• Description - Invoice: 4OCTBXw/PLSTR EAR 1-1/2DP NMSC&1/2KO
• Freight Class Code: 06202000
• Harmonization Code: 7326908688
• Image Actual Or Representative: A
• MSDS Flag: Yes
• Order Multiple: 24 EA
• Replaced Catalog Number: 10050371
• Returnable Indicator: Yes
• Stock Indicator: S - Shelf Stock
• Sub Class Code: D012D0120
• Ceiling Fan Rated: No
• Drawn or Welded: Drawn
• Fixture Lbs.: 50 lb.
• Power Distribution Features: Fire Rated
• Raised Ground: No
• Wiring System: Nonmetallic Sheathed Cable
• Material: Steel
• Proposition 65 Warning Required: No
• Base Unit of Measure: EA
• BOX SIZE: 10.625x11.125x8.75 (in)
• Box Type: Ceiling Box
• Carton - Gross Weight per Pack: 14.45 lb.
• Carton - Number of Sub Packs: 24
• Carton - Pack Description: Carton
• Carton - SCC-14 Next Lower Level Sub Pack: 50169001509
• Carton - Total Units: 24 EA
• Each - Pack Description: Each
• Lowest Level UOM: Each
• Pallet - GTIN - Package: 80050169001505
• Pallet - Number of Sub Packs: 80
• Pallet - Pack Description: Pallet
• Pallet - SCC-14 Next Lower Level Sub Pack: 40050169001507
• Pallet - Total Units: 1920 EA
• Pallet Height: 47.375 in
• Pallet Length: 48.000 in
• Pallet Weight: 1215.560 lb.
• Pallet Width: 42.000 in
• Standard Package Quantity: 10

Certifications

• Certified Listed: UL Listed
• EU RoHS Indicator: Contact Manufacturer
