Features

• Secure wire bundles and harness components quickly, without slipping
• Curved tip allows for fasterthreading and installation
• Made in the USA
• UL Listed 62275 Type 21 or 21S and Plenum Rated AH-2 for use in air handling spaces

Specifications

• Manufacturer Catalog Number: 7000133470
• Cable Length (Imperial): 36 in
• Cable Length (Metric): 914.4 mm
• Cable Tie Base Height: 36 in
• Cable Tie Length: 914 mm
• Color Family (incorporate Product Color): Beige
• Flammability Rating: UL 94 V-2
• Manufacturing Origin: USA
• Material: Nylon 6/6
• Maximum Bundle Diameter: 11 Inch
• Maximum Bundle Diameter (Metric): 279 mm
• Maximum Insulation Outer Diameter (Metric): 3.7 mm
• Maximum Insulation Outside Diameter: 0.145 in
• Maximum Operating Temperature: 85 Degree Celsius
• Maximum Operating Temperature (Celsius): 85 Degree Celsius
• Maximum Operating Temperature (Fahrenheit): 185 Degree Fahrenheit
• Minimum Bundle Diameter: 1.5 Inch
• Minimum Bundle Diameter (Metric): 8.1 mm
• Minimum Installation Temperature (Celsius): 0 Degree Celsius
• Minimum Installation Temperature (Fahrenheit): 32 Degree Fahrenheit
• Minimum Operating Temperature (Celsius): -40 Degree Celsius
• Minimum Operating Temperature (Fahrenheit): -40 Degree Fahrenheit
• Operating Temperature (Celsius): 85 Degree Celsius
• Operating Temperature (Fahrenheit): 185 Degree Fahrenheit
• Operating Temperature Range (Celsius): 0 °C to 85 °C
• Operating Temperature Range (Fahrenheit): 32 °F to 185 °F
• Overall Length (Imperial): 36 in
• Overall Length (Metric): 914 mm
• Overall Width (Imperial): 0.335 in
• Overall Width (Metric): 8.5 mm
• Plenum Rated: Yes
• Tensile Strength (Imperial): 175 lbs
• Tensile Strength (Metric): 79.38 kg
• Type: Standard
• UV Resistant: No

Packaging

• Package Length: 5.00000 in
• Package Height: 40.00000 in
• Package Weight: 2.2990 LBS
