Features

• Rugged metallic construction ensures mechanical protection
• Insulated throat protects wires and reduces pulling effort
• O-ring secures he assembly and provides a raintight seal.
• UL Listed, CSA
• Available in trade sizes 1/2 in. through 4 in.

Specifications

• Country of Origin: India
• Buy American Compliant: Contact Manufacturer
• Dimensions: 1.473 in x 1.685 in x 1.685 in
• Width: 1.685 in
• Each - Width: 1.685 in
• Height: 1.685 in
• Industry Standard(s): UL 514B
• Insulation Type: Insulated
• Product Type: Commercial Fittings
• Length: 1.473 in
• Size: 1.473 in x 1.685 in x 1.685 in
• Standard: UL 514B
• Environmental Conditions: Wet Location
• Trade Size: 3/4 in
• Weight: 0.259 lb.
• ARRA Compliant: Contact Manufacturer
• Class Code: D04
• Description - Invoice: RGD/IMC HUB 3/4 IN INSUL DIE CAST ZINC
• Freight Class Code: 06202000
• Harmonization Code: 8547900030
• Image Actual Or Representative: R
• Lead Time: 21 wk
• MSDS Flag: Yes
• Order Multiple: 25 EA
• Returnable Indicator: Yes
• Stock Indicator: S - Shelf Stock
• Sub Class Code: D043D0438
• Fitting Type: Hubs
• Conduit Type: Rigid/IMC
• Material: Die Cast Zinc
• Base Unit of Measure: EA
• BOX SIZE: 5.7x7.8x5.5 (in)
• Carton - Gross Weight per Pack: 6.478 lb.
• Carton - Number of Sub Packs: 25
• Carton - Pack Description: Carton
• Carton - SCC-14 Next Lower Level Sub Pack: 50169017036
• Carton - Total Units: 25 EA
• Each - Pack Description: Each
• Item Package Type: Carton
• Lowest Level UOM: Each
• Pallet - GTIN - Package: 70050169017035
• Pallet - Number of Sub Packs: 335
• Pallet - Pack Description: Pallet
• Pallet - SCC-14 Next Lower Level Sub Pack: 50050169017031
• Pallet - Total Units: 8375 EA
• Pallet Height: 24.875 in
• Pallet Length: 48.000 in
• Pallet Weight: 2215.130 lb.
• Pallet Width: 42.000 in

Certifications

• Certified Listed: UL Listed;CSA Certified
• EU RoHS Indicator: Contact Manufacturer
