Features

• Aluminum construction resists corrosion
• Neoprene grommet seals out oil and moisture
• Nylon retention ring ensures superior holding power
• Aluminum construction resists corrosion. Neoprene grommet seals out oil and moisture. Nylon retention ring ensures superior holding power.

Specifications

• Country of Origin: United States
• Buy American Compliant: Contact Manufacturer
• Dimensions: 1.29 in x 0.55 in x 1.1 in
• Width: 0.550 in
• Each - Width: 0.550 in
• Hazardous Rating(s): Suitable for use in hazardous location applications when installed according to NEC Articles 501.10(b) (Class I, Division 2) or 502.10, 503.10, and 505.15 (Class I Zone 2).
• Height: 1.1 in
• Hub Size: 3/4"
• Length: 1.29 in
• Color: Silver
• Finish: Natural
• Size: 1.29 in x 0.55 in x 1.1 in
• Special Features: Aluminum construction resists corrosion. Neoprene grommet seals out oil and moisture. Nylon retention ring ensures superior holding power.
• Type: Straight Cord Connector
• Finish Type: Natural
• ARRA Compliant: Contact Manufacturer
• Class Code: D30
• Description - Invoice: CONN STR 3/4" .187-.250 EX
• Freight Class Code: 06168002
• Harmonization Code: 7616995190
• Image Actual Or Representative: R
• Lead Time: 25 wk
• MSDS Flag: No
• Order Multiple: 25 EA
• Returnable Indicator: Yes
• Sub Class Code: D30D238
• Cable Range: .187 - .250 in
• Cord Range: .187-.250,
• CSA File Number: LR73478
• Gross Weight with Packaging: 0.12
• UL File Number: E22698
• Color Code: Red
• Material: Aluminum, Copper Free (less than 4/10 of 1%)
• Series: Z Series EX
• Base Unit of Measure: EA
• BOX SIZE: 1.100x1.290x0.550 (in)
• Carton - Gross Weight per Pack: 3.000 lb.
• Carton - Number of Sub Packs: 25
• Carton - Pack Description: Carton
• Carton - SCC-14 Next Lower Level Sub Pack: 00783936972428
• Carton - Total Units: 25 EA
• Master Pack Description: Each

Certifications

• EU RoHS Indicator: Contact Manufacturer
