Features

Ballasting Requirements

• Ballast Bypass

Specifications

• Country of Origin: China
• Weight: 1.1 Lbs.
• Substitute: S13163
• Warranty: 5 Year Limited - Hi-Pro
• Amps: 0.250-0.090A
• ANSI Base: EX39
• Ballast Bypass Direct: Ballast Bypass
• Beam Spread: 280
• CCT Selectable: No
• CO Terse: Lawful for sale
• HI Terse: Lawful for sale
• NV Terse: Lawful for sale
• VT Terse: Lawful for sale
• Color Temp: Natural Light
• CRI: 80
• Dimmable: Non-Dimmable
• DLC Approved: No
• Enclosure Rating: Enclosed Rated Lamp
• ENERGY STAR: No
• FCC Compliant: Yes
• Finish: Frost
• Product Type: Type A
• HID Equiv: 100W
• Avg Rated Hours: 50000
• Housing Color: White
• Incandescent Equiv: 200W
• Lamp Base: Mogul Extended
• Lamp Filament: LED
• Lamp Shape: A23
• Lamp Ballast Type A/B/C: Type B
• Lensed: Lensed Lamp
• Lens Finish: Frost
• Lens Material: Plastic (PS)
• Lumens: 3525L
• Material: Plastic
• Minimum Compartment Size: Diameter: 6 in. Height: 8.5 in.
• MOD Decimal: 3.22 in.
• MOL Decimal: 6.66 in.
• Operating Frequency: 50/60 Hz
• Operating Temp: -25C (-13F) to +45C (+113F)
• Power Factor: >0.9
• Rated For Enclosed Fixture: Yes
• RoHS Compliant: Yes
• Safety Listing: cULus - Listed
• Location Rating: Damp
• Technology: LED
• Temperature (CCT): 5000K
• Volts: 100V-277V
• Watts: 25W
