Features

• Provides up to 96 operations (48 ON/48 OFF) every 24 hours
• Models with skipper wheel allow for operations to be omitted on selected days of the week
• 15-minute intervals
• Captive trippers slide in and out of dial for fast, accurate setting

Compliance

• CSA Certification File Number -> C22.2-177; LR3730

Prop 65

• Please see the Warning @ www.P65Warnings.ca.gov - Lead

Specifications

• Country of Origin: Mexico
• Product Height: 7.875 in; 200 mm
• Product Depth: 3.4375 in; 87.3 mm
• Operating Temperature Min: -40°F; -40°C
• Operating Temperature Max: 130°F; 54°C
• Warranty Period: 1-Year limited
• Minimum On Off Time: 15 min
• Maximum On Off Operations: 48
• Skipper Wheel Operation Mode: Not Included
• Operation Mode: 24 hour
• Applications: Timing/Scheduling ON/OFF; Indoor Lighting Control
• Wire Size Min: #14 AWG
• Wiring Option: Terminals
• Input Voltage Ranges: 125 VAC, 60 Hz
• Wire Size Max: #12 AWG
• Number Of Circuits: 1
• Enclosure Type: Indoor type 1 metal
• Switch Type: SPDT
• Power Consumption Max W: 3 W
• Number Of Trippers Included: 96
• Has Manual Override CVL: Yes
• PDF Standards And Certifications: cCSAus

Certifications

• CSA Certification: cCSAus

Load Ratings

• Resistive Load Ratings: 20 A, 125 VAC, 60 Hz; 20 A, 208 VAC, 60 Hz; 20 A, 240 VAC, 60 Hz; 20 A, 277 VAC, 60 Hz; 20 A, 480 VAC, 60 Hz
• Resistive Load Ratings Ranges: 20 A, 125-480 VAC, 60 Hz
• Motor Load Ratings Ranges: 1/2 HP, 125 VAC, 60 Hz; 1 HP, 250 VAC, 60 Hz
