Features

• Controls single- and two-speed pumps and cleaner/booster pumps
• Three ON/OFF events per circuit per day
• Seven preprogrammed modes
• Freeze and heater protection
• LCD readout
• Multivoltage input and output
• Countdown and override features enable programs to be overridden and automatically resumed without requiring the user to reprogram the system

Prop 65

• Please see the Warning @ www.P65Warnings.ca.gov - DEHP

Specifications

• Country of Origin: Canada
• Product Height: 9.375 in; 238 mm
• Product Depth: 3.625 in; 92 mm
• Warranty Period: 1-Year limited
• Maximum On Off Operations: 3
• Operation Mode: 24 hour
• Voltage Selection Type: Multi Voltage
• Applications: Motor Control; Pump Control
• Input Voltage Ranges: 120/240 VAC, 50/60 Hz
• Enclosure Type: Outdoor type 3R plastic
• Switch Type: 3-SPST
• PDF Standards And Certifications: cCSAus

Certifications

• CSA Certification: cCSAus

Load Ratings

• Tungsten Load Ratings: 5 A, 120 VAC, 50 Hz; 5 A, 240 VAC, 50 Hz; 5 A, 120 VAC, 60 Hz; 5 A, 240 VAC, 60 Hz
• Tungsten Load Ratings Ranges: 5 A, 120/240 VAC, 50/60 Hz
• Resistive Load Ratings: 17 A, 120 VAC, 50 Hz; 17 A, 240 VAC, 50 Hz; 17 A, 120 VAC, 60 Hz; 17 A, 240 VAC, 60 Hz
• Resistive Load Ratings Ranges: 17 A, 120/240 VAC, 50/60 Hz
• Motor Load Ratings Ranges: 80 LRA @ 120/240 VAC, 50/60 Hz; 17 FLA @ 120/240 VAC, 50/60 Hz
