Features

• Emits no UV light
• Contains no Mercury (Hg)
• Acceptable for use in food prep areas

Ballasting Requirements

• Ballast Bypass- Direct wire only 100V-277V

Specifications

• Country of Origin: China
• Weight: 0.68 Lbs.
• Substitute: S49671
• Warranty: 5 Year Limited - Hi-Pro
• Amps: 0.220-0.079A
• ANSI Base: E26
• Ballast Bypass Direct: Ballast Bypass
• Beam Spread: 300
• Burning Position: Universal
• CCT Selectable: No
• CO Terse: Lawful for sale
• HI Terse: Lawful for sale
• NV Terse: Lawful for sale
• VT Terse: Lawful for sale
• Color Temp: Warm White
• Common Purpose: Industrial and commercial applications
• CRI: 80
• Dimmable: Non-Dimmable
• Enclosure Rating: Enclosed Rated Lamp
• ENERGY STAR: No
• FCC Compliant: Yes
• Finish: Clear
• Product Type: Corncob
• Flr Equiv: 40W
• HID Equiv: 100W
• Avg Rated Hours: 50000
• Housing Color: White
• Incandescent Equiv: 150W
• Indoor Outdoor: Indoor and Outdoor
• IP Rating: IP64
• Lamp Base: Medium
• Lamp Filament: LED
• Lamp Shape: Corncob
• Lamp Ballast Type A/B/C: Type B
• Lensed: Lensed Lamp
• Lens Finish: Clear
• Lens Material: Plastic (PS)
• Lumens: 2860L
• Material: Aluminum / Plastic
• Minimum Compartment Size: Length: 8.5 in. Width: 6 in. Depth: 6 in.
• MOD Decimal: 2.38 in.
• MOL Decimal: 5.94 in.
• Operating Frequency: 50/60 Hz
• Operating Temp: -25C (-13F) to +45C (+113F)
• Power Factor: >0.9
• Rated For Enclosed Fixture: Yes
• Replaces: S29671
• RoHS Compliant: Yes
• Safety Listing: cULus - Listed
• Location Rating: Damp
• Shatter Proof Type: Shatter resistant materials
• Surge Protection: Built-in surge protection - 2.5KV
• Technology: LED
• Temperature (CCT): 2700K
• Volts: 100V-277V
• Watts: 22W
• Working Voltage: AC 90-305V
