Features

• Corrosion-resistant, plated steel strap locked into assembly to prohibit strap from bending away from body.
• Heavy-duty compact design for easier installation and long lasting performance.
• Easily accessed break-off, line-contact connecting tab for fast, easy split-circuit wiring.
• Impact-resistant nylon face.
• Terminal compartments isolated from each other for positive conductor containment.
• All devices fit standard #26 opening wall plate.
• Tri-drive terminal and mounting screws.
• Auto-ground clip assures positive ground.
• Temperature Rise: Maximum 30°C temperature rise at full-rated current after 50 cycles of overload at 150% of rated current with direct current. Operating Temperature: Maximum continuous +60°C, minimum -40°C without impact

Certifications

• cULus Listed
• Federal Spec Listed

Specifications

• Depth: 0.78 in
• Height: 2.635 in
• Width: 1.322 in
• Country of Origin: Mexico

Specifications

• Product Line: Pass & Seymour
