Features

• Impact-resistant nylon face.
• .032 inch thick, brass, triple-wipe power contacts for lasting retention.
• Easily accessible break-off line contact connecting tab for split circuit wiring.
• Corrosion-resistant, zinc-plated steel strap is locked in.
• Internal screw-pressure-plate back wire and side wire line terminals accept #14 : #10 AWG copper or copper-clad conductors.
• High strength thermoplastic back body.
• Auto-ground clip assures positive ground.
• Compact design for easy installation.
• Tri-drive terminal and mounting screws.
• Temperature Rise: Maximum 30°C temperature rise at full-rated current after 50 cycles of overload at 150% of rated current with direct current. Operating Temperature: Maximum continuous +60°C, minimum -40°C without impact

Certifications

• cULus Listed
• Federal Spec Listed

Specifications

• Depth: 0.78 in
• Height: 3.281 in
• Width: 1.322 in
• Country of Origin: Mexico

Specifications

• Color: Ivory
• Finish: Matte
• Product Line: Pass & Seymour
