Description
Features
- Die-Cast from High Strength, Corrosion and Weather Resistant Aluminum Alloy
- Smooth, Tapered NPT Threaded Hub
- Flat Back Design Allows Easy Mounting Close to Wall
- Attach to Either Rigid Conduit or EMT When it is Necessary to Correct or Change the Direction of Conduit Runs
- Provide Access to Conductors When Wire Pulling, Splicing or for Maintenance
- Make 90 Degree Bends in Conduit Runs
Additional Information
- Style Assembled
- Internal Volume 306 Cubic Inch
- Wire Size (3) #350 MCM
- Includes Neoprene Rubber Gasket
Specifications
- Access Opening: Left Side
- Configuration: LL
- Cover Type: Galvanized Steel
- Hub Location: 90 Degree
- Number of Hubs: 2
- Hub Size: 3-1/2 Inch
- Size: 5.51 Inch Length x 14.88 Inch Width x 11.7 Inch Height
- Installation: Threaded
- Material: Electrostatic Powder Coated Die-Cast Aluminum
- Approval: UL, UL 514A, CSA C22.2
- Used On: IMC/Rigid Conduit
Downloads
Specification/TechnicalCatalog
Other 1
More Information
Manufacturer Catalog Number
12819
Weight
930.0000
Material
Electrostatic Powder Coated Die-Cast Aluminum
Product Size
11.7 inches
