Features

• Available in InstantFit plug-and-play (UL Type A) or MainsFit (Type B) Options
• MainsFit T5 (Type B/Ballast Bypass) are double-ended for quick installation
• Easy installation. Retrofit replacement of existing T5 lamps
• 2ft and 3ft InstantFit lamps operate on both HE and HO ballasts

Benefits

• Instantly reduces lighting costs
• True T5 size fits conventional applications
• One lamp for both HE and HO applications (2ft/3ft lamps)

Applications

• Industrial & warehouses
• Retail & hospitality
• Parking lots and covered car parks

Specifications

General Information

• Base: G5 [ G5]
• EU RoHS compliant: Yes
• Nominal Lifetime (Nom): 50000 h
• Switching Cycle: 50000X

Light Technical

• Color Code: 830 [ CCT of 3000K]
• Beam Angle (Nom): 200 °
• Initial lumen (Nom): 1400 lm
• Color Designation: White (WH)
• Correlated Color Temperature (Nom): 3000 K
• Luminous Efficacy (rated) (Nom): 127.00 lm/W
• Color Consistency: <6
• Color Rendering Index (Nom): 82
• LLMF At End Of Nominal Lifetime (Nom): 70 %

Operating and Electrical

• Input Frequency: 40000-110000 Hz
• Power (Rated) (Nom): 11 W
• Lamp Current (Max): 400 mA
• Lamp Current (Min): 60 mA
• Starting Time (Nom): 0.5 s
• Warm Up Time to 60% Light (Nom): 0.5 s
• UL Type: Type A - works on ballast
• Power Factor (Nom): 0.9
• Voltage (Nom): 50-80 V

Temperature

• T-Ambient (Max): 45 °C
• T-Ambient (Min): -20 °C
• T-Storage (Max): 65 °C
• T-Storage (Min): -40 °C
• T-Case Maximum (Nom): 70 °C

Controls and Dimming

• Dimmable: Yes

Mechanical and Housing

• Product Length: 36 in

Approval and Application

• Energy Saving Product: Yes
