Specifications

• Country of Origin: China
• Candlepower: 240
• Width: 4.72 In.
• Height: 1.02 In.
• Weight: 0.71 Lbs.
• Warranty: 5 Year Limited - Fixtures
• Air Tight: Yes
• Beam Spread: 108
• Bulb Included: Integrated
• CCT Selectable: Yes
• Ceiling Aperture: 4.25 in. Cutout
• Clearance Height: 2
• Color Temp: Warm to Cool White
• Connection: Direct Wire
• CRI: 90
• Diameter: 4.72 in.
• Dimmable: Yes-Dimmable
• ENERGY STAR: Yes
• ES Unique ID: ESID-2369679
• ES Category: Downlight Recessed
• FCC Compliant: Yes
• Finish: White
• Finish Family: White
• Fixture shape: Round
• Product Type: Direct Wire LED Downlight
• Has Driver: Yes
• Avg Rated Hours: 50000
• IC Rated: Yes
• Incandescent Equiv: 45W
• Indoor Outdoor: Indoor
• IP Rating: IP20
• Lamp Shape: Integrated LED
• Lens Finish: Frost
• Lens Material: Poly methyl methacrylate (PMMA)
• Lumens: 650L
• Material: Aluminum
• Max Dry Wall Thickness (In.): 1/2 in.
• Operating Frequency: 60 Hz
• Operating Temp: -20C (-4F) to +45C (+113F)
• Power Factor: >0.9
• Rec Spacing Between Fixtures: 3 ft. to 4 ft.
• Replaceable Light Source: No
• Replaces: S11600; S11601; S11602
• RoHS Compliant: Yes
• Safety Listing: cETLus - Listed
• Location Rating: Wet
• Sloped Ceiling Compatible: No
• Style: Utility
• Technology: LED
• Temperature (CCT): 2700K/3000K/3500K/4000K/5000K
• THD: <20%
• Trim Color: White
• Volts: 120V
• Watts: 10W
